If you have any specific query about the mini project or want to share the results of this project, please post them on course discussion forum.
#Ansys icem cfd pdf#
You can also download PDF instruction file from “Shared Files” section on lesson page. Its compressed zip files, so download and unzip the file to get PDF copy. You can download the PDF copy with details of this mini project from link below. Use geometry dimensions given above to create the geometry. This mini project does not require any input files. Once the missile and external domain geometry is created, you need to create following parts to assign boundary conditions: You need to decide what extent of CFD domain should be considering the external flow requirements.įigure 1: Geometry details (Note: All dimensions are in mm.) As shown in the Figure 2, a CFD domain needs to be created around the missile geometry for external flow simulation. All geometry dimensions are given in Figure 1. The geometry is to be generated to carryout external flow CFD simulation. The objective of this assignment is to create the missile geometry in 2D using ANSYS ICEMCFD. Missile geometry given in this problem is typical missile geometry used in aerospace industry. The functionalities you need to use to complete this test are well explained in lessons “Geometry creation in ANSYS ICEMCFD”. Before taking this assignment, please make sure that you have gone through necessary lessons. The main pre-requisite for this assignment is basic understanding of geometry creation available in ANSYS ICEMCFD.
After completing this mini project you will be comfortable in geometry creation/repair operations for simple geometries. This mini project tests your understanding of various geometry creation options available in ANSYS ICEMCFD. This mini project /assignment deals with the geometry creation for 2D missile geometry.
